“MEMS-based LiDAR sensors are usually less expensive, but they are not high-performance enough for use in autonomous vehicles.” We hear sentiments like this quite often. In this blog post we will explain how our sensors effectively invalidate this assumption, how we found the perfect mirror size for our LiDAR, and what considerations factored in to our decisions.
For use in autonomous vehicles, LiDAR sensors have to meet two basic requirements: on the one hand, they have to deliver high performance, including long range and a wide field of view. On the other hand, they must also be scalable so that millions can be produced and installed in vehicles. LiDAR manufacturers meet these challenges through various approaches. Mechanical LiDAR systems, whose beam deflection units are moved mechanically by motors, are still the most commonly used systems today. Although these devices boast a wide field of view — some up to 360° — and long range, their mechanics require regular maintenance and are large, heavy, and expensive to produce. Thus, mechanical LiDAR systems solve only the performance side of the two major demands placed on the sensor industry.
Another approach to meet these challenges is MEMS (microelectromechanical systems) technology. Here, components are produced in silicon, which has the advantage of scalability: since this technology has been tried and tested over many years, identical components can be produced in a cost-efficient manner and in large quantities. This approach is also used, among other things, in the production of microsensors.
But how do MEMS-based LiDAR systems meet the challenges of performance?
Long range with the help of the right laser source
For autonomous vehicles to be able to travel at high speeds, they must be able to “see” and perceive the world around them — not only in their immediate vicinities, but also at greater distances. This is particularly important when driving on highways, as vehicles are moving faster and therefore objects, bends, and other vehicles must be reliably detected at greater distances in order to be able to react in good time. Sensors therefore require a long range in order to enable autonomous driving at highway speeds.
In order to achieve this range with a LiDAR sensor, either the emitter or the detector needs to be optimized specifically for this application.
One possible starting point for such adjustments is the laser source. Typically, lasers with two different wavelengths are used in LiDAR sensors. Some LiDAR manufacturers rely on fiber lasers with wavelengths of 1550 nm. This wavelength cannot be focused by the human eye and can thus be used in an eye-safe manner even at high energy levels. This results in a longer range — the more energy used, the further the device “sees”. However, this type of laser source also has a decisive disadvantage: 1550 nm lasers are large and complex to manufacture, which leads to higher prices and large LiDAR housing dimensions.
Many LiDAR applications therefore use laser diodes that emit laser pulses with wavelengths of 905 nm. These have the distinct advantage of being very small and having been used for a long time in a wide variety of applications. As a result, these diodes are inexpensive and available on the market in large quantities. However, eye safety regulations require that the beam strength of the diodes be lower than that of 1550 nm lasers. The optimization on the emitter side is therefore limited.
Searching for the right mirror size
So how can the detector be optimized? Here the aperture plays an important role in achieving long ranges. It describes the size of the detector. In the case of our MEMS-based design, the aperture corresponds to mirror size. In order to capture as much light as possible, a large aperture — in other word as large a mirror as possible — is required. However, mirror size is also limited by certain factors – and so it is necessary to calculate the optimal mirror size while taking these into account. These factors are: photon number to be received, collimation, deflection angle, and resonance frequency.
Photon number
On the one hand, the size of the mirror used in LiDAR unit depends on how many photons have to be emitted in order for a sufficient number of photons to come back, thereby detecting an object. This minimum number of photons can be calculated accurately based on the link budget. This measure includes how many photons are lost at distance and through low reflective surfaces, homogeneous scattering of light, and detector inefficiency. In this way, it is possible to calculate how many photons must be emitted, or how large the aperture must be so that a minimum number of photons can be detected again. In addition, Blickfeld sensors have a coaxial design, which means that only the light that comes back from the same direction in which it was emitted is recaptured. This is advantageous in that it prevents other random light signals from being picked up and disturbing or falsifying the images.
Collimation
In order to obtain high-resolution data that reliably identifies even small objects, the lasers must hit objects in a collimated form. This collimation is achieved by placing a lens in front of the laser. Now the mirror size comes into play again: a mirror must be exactly large enough to deflect all the light collimated by the lens. This depends on the focal length required for optimal collimation and thus high resolution.
Resonant frequency
MEMS mirrors oscillate at a certain resonant frequency. They are triggered by integrated actuators and therefore do not require motors or any other mechanical means. This is a clear advantage because motors and moving parts quickly wear out and require regular maintenance. These problems do not arise if the oscillation is triggered by integrated actuators.
The resonant frequency at which a mirror oscillates depends on the size and mounting of the mirror. For this purpose we have developed a proprietary technique for embedding the mirrors in order to be able to use particularly large mirror sizes. Due to these unusually large diameters, a large number of photons can be directed into the surroundings and back onto the detector, which allows Blickfeld LiDAR sensors to achieve accurate a long range. In addition, thanks to their larger size, these mirrors are more robust than conventional products, which are only a few millimeters in diameter. Mirrors used in Blickfeld LiDARs also have high resonant frequencies due to their lightweight construction, which ensures that the greatest possible number of photons are returned to the detector: if the mirror oscillates too quickly or too slowly, photons will pass the detector due to the coaxial structure.
MEMS technology specifically designed for LiDAR applications
In conclusion, mirror sizes are determined by a wide array of factors. In order to build the most high-performance LiDARs based on MEMS, mirrors must have specially developed compositions, sizes, and embeddings. And only if the MEMS technology is specifically developed with LiDAR applications in mind, can the requirements of a long range, a wide field of view, and high resolutions be achieved.
At the heart of sensors – MEMS technology for LiDAR
/in Posts, Blog /by Blick Feld“MEMS-based LiDAR sensors are usually less expensive, but they are not high-performance enough for use in autonomous vehicles.” We hear sentiments like this quite often. In this blog post we will explain how our sensors effectively invalidate this assumption, how we found the perfect mirror size for our LiDAR, and what considerations factored in to our decisions.
For use in autonomous vehicles, LiDAR sensors have to meet two basic requirements: on the one hand, they have to deliver high performance, including long range and a wide field of view. On the other hand, they must also be scalable so that millions can be produced and installed in vehicles. LiDAR manufacturers meet these challenges through various approaches. Mechanical LiDAR systems, whose beam deflection units are moved mechanically by motors, are still the most commonly used systems today. Although these devices boast a wide field of view — some up to 360° — and long range, their mechanics require regular maintenance and are large, heavy, and expensive to produce. Thus, mechanical LiDAR systems solve only the performance side of the two major demands placed on the sensor industry.
Another approach to meet these challenges is MEMS (microelectromechanical systems) technology. Here, components are produced in silicon, which has the advantage of scalability: since this technology has been tried and tested over many years, identical components can be produced in a cost-efficient manner and in large quantities. This approach is also used, among other things, in the production of microsensors.
Long range with the help of the right laser source
For autonomous vehicles to be able to travel at high speeds, they must be able to “see” and perceive the world around them — not only in their immediate vicinities, but also at greater distances. This is particularly important when driving on highways, as vehicles are moving faster and therefore objects, bends, and other vehicles must be reliably detected at greater distances in order to be able to react in good time. Sensors therefore require a long range in order to enable autonomous driving at highway speeds.
One possible starting point for such adjustments is the laser source. Typically, lasers with two different wavelengths are used in LiDAR sensors. Some LiDAR manufacturers rely on fiber lasers with wavelengths of 1550 nm. This wavelength cannot be focused by the human eye and can thus be used in an eye-safe manner even at high energy levels. This results in a longer range — the more energy used, the further the device “sees”. However, this type of laser source also has a decisive disadvantage: 1550 nm lasers are large and complex to manufacture, which leads to higher prices and large LiDAR housing dimensions.
Many LiDAR applications therefore use laser diodes that emit laser pulses with wavelengths of 905 nm. These have the distinct advantage of being very small and having been used for a long time in a wide variety of applications. As a result, these diodes are inexpensive and available on the market in large quantities. However, eye safety regulations require that the beam strength of the diodes be lower than that of 1550 nm lasers. The optimization on the emitter side is therefore limited.
Searching for the right mirror size
So how can the detector be optimized? Here the aperture plays an important role in achieving long ranges. It describes the size of the detector. In the case of our MEMS-based design, the aperture corresponds to mirror size. In order to capture as much light as possible, a large aperture — in other word as large a mirror as possible — is required. However, mirror size is also limited by certain factors – and so it is necessary to calculate the optimal mirror size while taking these into account. These factors are: photon number to be received, collimation, deflection angle, and resonance frequency.
Photon number
On the one hand, the size of the mirror used in LiDAR unit depends on how many photons have to be emitted in order for a sufficient number of photons to come back, thereby detecting an object. This minimum number of photons can be calculated accurately based on the link budget. This measure includes how many photons are lost at distance and through low reflective surfaces, homogeneous scattering of light, and detector inefficiency. In this way, it is possible to calculate how many photons must be emitted, or how large the aperture must be so that a minimum number of photons can be detected again. In addition, Blickfeld sensors have a coaxial design, which means that only the light that comes back from the same direction in which it was emitted is recaptured. This is advantageous in that it prevents other random light signals from being picked up and disturbing or falsifying the images.
Collimation
In order to obtain high-resolution data that reliably identifies even small objects, the lasers must hit objects in a collimated form. This collimation is achieved by placing a lens in front of the laser. Now the mirror size comes into play again: a mirror must be exactly large enough to deflect all the light collimated by the lens. This depends on the focal length required for optimal collimation and thus high resolution.
Resonant frequency
MEMS mirrors oscillate at a certain resonant frequency. They are triggered by integrated actuators and therefore do not require motors or any other mechanical means. This is a clear advantage because motors and moving parts quickly wear out and require regular maintenance. These problems do not arise if the oscillation is triggered by integrated actuators.
The resonant frequency at which a mirror oscillates depends on the size and mounting of the mirror. For this purpose we have developed a proprietary technique for embedding the mirrors in order to be able to use particularly large mirror sizes. Due to these unusually large diameters, a large number of photons can be directed into the surroundings and back onto the detector, which allows Blickfeld LiDAR sensors to achieve accurate a long range. In addition, thanks to their larger size, these mirrors are more robust than conventional products, which are only a few millimeters in diameter. Mirrors used in Blickfeld LiDARs also have high resonant frequencies due to their lightweight construction, which ensures that the greatest possible number of photons are returned to the detector: if the mirror oscillates too quickly or too slowly, photons will pass the detector due to the coaxial structure.
MEMS technology specifically designed for LiDAR applications
In conclusion, mirror sizes are determined by a wide array of factors. In order to build the most high-performance LiDARs based on MEMS, mirrors must have specially developed compositions, sizes, and embeddings. And only if the MEMS technology is specifically developed with LiDAR applications in mind, can the requirements of a long range, a wide field of view, and high resolutions be achieved.
Looking Back: This Was 2019
/in Company News, Posts /by Blick FeldIf we had to give 2019 a title, it would be “growth”: Our product family has grown, built up our production and significantly expanded our team. And an end to growth is not in sight!
Before 2019 is over, we want to take a look at some of the events of the last twelve months. This was 2019 for Blickfeld:
Turning one into two
The expansion of our product family with our long-range sensor, the Cube Range, was certainly one of the most important steps for Blickfeld this year. We can now offer a full automotive LiDAR suite: The “family eldest”, the Cube, covers the middle- and closer-range vehicle environment with a wide field of view. This is particularly important for urban driving scenarios, where many road users are involved, all of which must be detected by the sensor. The new Cube Range complements the Cube with long-range detection, which reliably detects even dark and low-reflecting objects at great distances and in high resolution.
Blickfeld on Tour
The Blickfeld year started in Las Vegas. At CES 2019, Blickfeld was to be found at several booths, including Leddartech, LiteOn and Koito. We enthusiastically immersed in the CES world – our conclusion: All autonomous everything. Click here for our report on CES 2019.
But CES was not the only big fair Blickfeld was present at this year. Industry get-togethers such as AutoSens in Detroit or Brussels and the IAA in Frankfurt also were an integral part of Blickfeld’s event calendar. In addition, there were numerous other events all over the world where Blickfeld was present with a booth or where our LiDAR experts spoke.
Blickfeld sparkles
It is always important for us to know that we are on the right track with our products and our strategy. The fact that we have won important awards and prizes this year confirms that the autonomous mobility of the future is moving ever further into focus and affects us all. We would particularly like to highlight the German Innovation Prize, the European Start-up Prize for Mobility, the Start me up Founder’s Prize and, most recently, “The Spark”, awarded under the patronage of the Federal Ministry of Economics and Energy.
Ready to ramp up
2019 was also an important year on the way to series production of our LiDAR sensors. We have teamed up with a production partner who has many years of experience in the manufacture of optoelectronic products in the automotive sector and with whom we have built up a highly automated production line.
Focus on vehicle design
At the end of May, we were happy to announce that we are working together with the Japanese Tier One automotive supplier Koito to integrate our solid-state LiDAR into car headlights. Together, we are working to seamlessly integrate the sensor to not disturb the vehicle design.
An end to growth is not in sight
Our total team size has increased by an incredible third! In January, with a total of 61 colleagues, we already had a considerable team size for a start-up less than two years old. We will end 2019 with 99 employees. It’s a good thing that we anticipated this growth and expanded our office in the heart of Munich at the end of last year.
We are ready for 2020!
We are extremely pleased with the results achieved, very grateful to our team for their tireless commitment and look forward to continuing our good cooperation with our customers and partners next year.
Award “The Spark” goes to LiDAR developer Blickfeld
/in Company News, Awards, Posts /by Blick FeldThe Munich-based start-up is awarded the “The Spark” by Handelsblatt and McKinsey for its pioneering LiDAR technology.
MUNICH, November 22, 2019 — Blickfeld, a leading provider of solid-state LiDAR technology, receives the German award “The Spark” by Handelsblatt and McKinsey which honors digital innovation. In a 90-second pitch on Thursday evening, co-founder Rolf Wojtech impressively presented the various applications of the scalable solid-state LiDAR sensors to the audience. The Munich-based start-up had already explained Blickfeld’s technology in detail to the eleven-member jury in September and thus prevailed against the other nine finalists in the competition.
The jury, which is made up of experts from various industry branches, including last year’s Spark winner Magazino, based their decision on the fact that Blickfeld was developing a “potential future technology of vital significance for the automotive industry”. They had evaluated the solutions presented by the finalists in terms of novelty, scalability and customer benefit.
“We got to know the other finalists at the jury meeting and have the utmost respect for each and every one of these start-ups,” says Mathias Müller, CEO of Blickfeld. “We are delighted that the jury has selected us as the winner of this year’s “The Spark” award. We also see the decision as further confirmation of the significance of LiDAR technology for autonomous driving. With this affirmation, we are continuing to enable the future of mobility with our Blickfeld sensors.”
With this year’s German Digital Award “The Spark”, Handelsblatt and McKinsey, under the patronage of the Federal Ministry of Economics and Energy, honored the thought leaders and entrepreneurs of the future for the fourth time. The prize is awarded to concepts that are innovative, scalable and have already been successfully tested.
Blickfeld to debut full automotive LiDAR suite at CES 2020
/in Company News, Posts /by Blick FeldLive demonstrations in Las Vegas to include CES 2020 Innovation Awards Honoree Blickfeld Cube
MUNICH — Blickfeld, a leading provider of solid-state LiDAR technology, will demonstrate its automotive-grade LiDAR sensors at the Consumer Electronics Show 2020 in Las Vegas. The Munich-based startup will show a live demo of its LiDAR suite, consisting of its two Blickfeld sensors, the Cube and Cube Range, in the Smart City exhibition area at Westgate, booth 1304, as well as in a live car demo.
Visitors can experience the different features of the two Blickfeld sensors: the Cube offers a wide field of view and is perfectly suited for urban driving applications. The latest addition to Blickfeld’s product portfolio, the Cube Range, was developed for long-distance detection, for example while driving at highway speeds. The public will be able to see the Cube Range in action for the first time, as Blickfeld is officially debuting its long-range sensor in Las Vegas. In combination, the Cube and Cube Range cover the full automotive LiDAR suite. Their capabilities will be featured in live product demonstrations at Blickfeld’s booth and on the streets of Las Vegas in a live car demo.
Blickfeld is also proud to announce that their solid-state LiDAR sensor, the Blickfeld Cube, has been named a CES 2020 Innovation Awards Honoree by the Consumer Technology Association (CTA). The CES Innovation Awards honor design and engineering in consumer technology products in various categories. The Cube was awarded in the category of Vehicle Intelligence & Transportation.
“We are very proud to have such a strong presence at CES in January and to be named a CES Innovation Awards Honoree,” says Blickfeld CEO Mathias Müller. “The booth and the demos are mirroring our journey of the last few months. We can look back on some important milestones in 2019: the launch of our long-range LiDAR, our step into mass production of the Cube, working with several Tier 1 manufacturers such as Koito — kicking off 2020 with an outstanding representation at CES fits in perfectly. And, without revealing too much, I can promise that the Blickfeld booth will be an eye-catcher — even aside from the point clouds.”
The Blickfeld Cube was named CES 2020 Innovation Awards Honoree
How to reduce congestion in cities
/in Posts, Blog /by Blick FeldSmart traffic with the help of LiDAR technology
If you have ever driven along the Mittler Ring in Munich during rush hour, you will be aware of the enormous problem facing urban spaces throughout the world: traffic jams as far as the eye can see. On average, Germans were stuck in traffic for 120 hours – and, in Munich, for as long as 140 hours – in 2018. For individuals, these lost hours are annoying and impair their quality of life. For the state, though, these figures mean considerable economic effects. Traffic jams cost several billion euros per year because employees are stuck in traffic jams instead of being productive, and goods are on the road instead of on the shelf. In addition, there is a high level of environmental pollution due to increased fuel consumption and thus increased CO2 emissions.
Traffic is a problem, especially in cities. However, new technologies can and will make an important contribution to solving this problem.
Knowing more than the individual road user
How does congestion develop? Traffic jams are a distributed problem caused by the fact that all road users drive their vehicles in a way that is optimized for themselves. For example, they may catch up with the car in front or change lanes – whatever appears to them to be the best way to get to their destination faster. Since the individual road users cannot see how they influence the traffic around them, they cannot act accordingly. Drivers themselves are not aware that a traffic jam can be triggered three kilometers behind the vehicle that is stopping.
This is the point at which we have to start: the behavior of individuals must be counterbalanced in traffic planning and control so as to optimize the flow of traffic. The solution is to regulate traffic in a pre-emptive and distributed manner, i.e. with anticipation and going beyond the individual road user. This requires a complete overview of the traffic situation.
Gaining a complete overview with GPS, cameras and sensors
Various technologies can be used to achieve this complete overview. However, if you take a closer look at them, you will see that some of them are less suitable for equipping a smart infrastructure:
GPS:
GPS provides valuable data by tracking the movements of road users. This technology can therefore be used to report traffic jams quite reliably. The ability to take pedestrians and cyclists into account, however, exceeds the capabilities of GPS.
Instead of collecting information with the help of road users, as in the case with GPS, sensors and cameras can be integrated into the infrastructure to monitor the traffic situation. This requires that the devices be installed in traffic lights, street lamps or traffic signs so that they can collect information about their surroundings from there. Here, too, clear advantages and disadvantages of the possible technologies can be identified:
Cameras:
Cameras, for example, are able to record color images, but they cannot provide the same quality when used in darkness. Additionally, they only capture the data in 2D, whereas 3D data is needed to reliably detect objects and determine distances. They also quickly find themselves in a grey area with regard to data protection when recording and storing personal data.
Radar:
Radar is mainly used for speed monitoring, but could also be used for traffic monitoring. However, radar only provides a very crude picture: although the technology identifies objects, it is not able to classify them due to the lack of detail. Radar data, for example, cannot reliably distinguish between pedestrians and cyclists.
LiDAR captures road users precisely and anonymously
Laser-based LiDAR technology is a technology that can distinguish very precisely between all road users. The sensors provide detailed and reliable 3D information that makes it easy to distinguish between different road users. Although it is possible to recognize whether the 3D point cloud is a pedestrian or a cyclist, the identification of individuals is not possible, which protects the privacy of road users.
In addition, LiDAR sensors are able to reliably collect information even in difficult weather and lighting conditions. Darkness, dust or fog do not bother the technology. In addition to position and object information, the sensors also record speeds, which can be helpful in analyzing traffic flow or the causes of traffic jams.
Solid-state as a solution for today’s LiDAR problems
High-tech sensors are currently used primarily in the field of autonomous driving, but they face a major challenge: the LiDAR sensors that are available today are expensive and prone to faults. Solid-state technology solves these problems. In this type of LiDAR, the moving parts that deflect the laser to scan the environment are replaced by maintenance-free components. The sensors are therefore much more robust and also less expensive – and hence ideally suited to a wide range of applications in the infrastructure.
Traffic information enables practical measures
The LiDAR sensors installed in the infrastructure provide information about the current traffic situation in real time: Is the traffic flowing or stagnating? Is there an accident or a construction site? Are there many pedestrians at the traffic lights or at the crosswalk?
With this information, the following measures can be taken in real time and adapted to the traffic in order to optimize the traffic flow:
In future we will even go one step further: autonomous vehicles will then use the information to dynamically adapt their schedules and routes to the traffic situation.
Cities that revolve around people again
In many cities, the influences of the paradigm of the “car-friendly city” can still be clearly seen today: urban planning is aligned to the goal of unhindered traffic flow by car. Even though this model has been subject to strong criticism for several decades now, many traffic concepts in cities are still oriented towards motorized individual transport.
In recent years, this approach has been increasingly replaced by a demand for car-free zones or even entire city centers. These demands clearly show that urban and traffic planning must once again be more about people. The needs of residents, commuters and all other road users must be centermost, which means making mobility as safe and uncomplicated as possible. Pedestrian crossings must be designed to be safer; turning accidents must be avoided; sufficient space must be created for cyclists – the list of measures is long. Intelligent traffic control with the help of a smart infrastructure makes this possible – and LiDAR technology is at the heart of it.
Blickfeld presents new long-range LiDAR
/in Company News, Posts /by Blick FeldCube Range detects obstacles at a distance of up to 250 meters
Munich – Blickfeld, a leading provider of solid-state LiDAR technology, is introducing the latest member of its product family. With the Cube Range, the Munich-based company is launching a MEMS-based LiDAR sensor for extended detection of objects at a distance of up to 250 meters. In combination with the well-established Blickfeld Cube, Blickfeld now offers a full LiDAR suite for autonomous vehicles.
The Cube Range sensor was designed as a robust and powerful 3D solid-state LiDAR for the mass market. It has a range of 150 meters with 10 percent reflection; a range of up to 250 meters is easily achievable with higher reflection. In addition, the Cube Range exhibits an impressive resolution of 0.18°.
The proven Blickfeld technology allows cost-effective and scalable production of the sensor. The core of this technology is a proprietary silicon MEMS mirror embedded in a coaxial structure that is based on commercial standard components.
Reliable and detailed collection of 3D data during a highway drive
With its high resolution and long range, the Cube Range addresses the need for moving objects to be detected with high accuracy. By precisely generating a dense 3D point cloud and then evaluating it in real time using Blickfeld’s software stack, the company makes an important contribution to enabling autonomous driving. The Blickfeld technology ensures precise environmental detection even in darkness, fog or strong sunlight.
“With the Cube Range, we have developed an extraordinary LiDAR which, thanks to its outstanding properties, is particularly suitable for driving at highway speed because it provides reliable environmental images even under these conditions,” says Dr. Mathias Müller, co-founder and CEO of Blickfeld. “Autonomous vehicles are just one application example for our LiDAR sensors. We also see a great demand in other areas, such as security, agriculture and smart city environments. Therefore, we are all the more pleased that the Cube Range has already proven itself successfully in various projects and will be available for purchase in 2019.”
IAA review: An industry on the road to change
/in Posts, Events /by Blick FeldThere was much talk, writing and discussion about this year’s IAA. There were lively and excited debates about a necessary change of the trade fair format as well as the entire industry. Blickfeld was on site with two booths. We would like to share our firsthand experience: here’s our impression.
One major novelty at this year’s IAA, was the New Mobility World (NMW) Conference, a three-day conference within the framework of the trade fair in which speakers from a wide variety of companies and organizations discussed current mobility topics. Both, the speakers and the dominant topics of the conference show that the mobility industry is changing. Ola Källenius, the new chairman of Daimler, joined Ginni Rometty, CEO of IBM, on stage, and names such as Qualcomm and Facebook were among the sponsors of the conference – this clearly shows that the IAA no longer only belongs to car manufacturers and suppliers. Topics such as connectivity, mobility-as-a-service and autonomous vehicles are gaining importance with more and more IT companies, start-ups and providers of new mobility presenting at booths and podiums.
The industry is looking at new and alternative mobility concepts. While the OEMs focused on electromobility at their booths, Tier 1 suppliers often designed their IAA presence around autonomous applications. One of these suppliers was Webasto, who unveiled their new “Roof Sensor Module”. The module is designed to smoothly integrate sensors in autonomous vehicles without bulky constructions on the roof of the cars. The module is capable to include the Blickfeld Cube, which is why Blickfeld sensors could not only to be found at the company’s own booths, but also at the Webasto booth.
The shift in the industry is important and necessary, as demonstrated by the protesters on the doorstep of the IAA. The industry will have to reorient to some extent. In the long term, autonomous driving will contribute to reducing vehicle emissions worldwide – the importance of this development was accentuated by Waymo CEO John Krafcik opening the show together with Angela Merkel. The Google sister Waymo drives many thousands of testing miles autonomously in California every month and is regarded a pioneer among the manufacturers of autonomous vehicles.
In the NMW exhibition area, Blickfeld was in good company: Start-ups in the fields of HD mapping, ultrasonic sensor technology, connected car, shared mobility, smart charging and many more were exhibiting. Here, too, there was a clear focus on autonomous driving.
The future of autonomous driving was further discussed by Blickfeld founder, Dr. Florian Petit, with his lecture on when self-driving will be the new normal on the NMW Conference stage. Florian took a critical look at the status quo in the areas of technology as well as legislation and customer acceptance of autonomous applications and gave an outlook on the developments of the upcoming years.
LiDAR pioneer Blickfeld wins Germany’s highest endowed start-up prize against 1,200 participants
/in Company News, Awards, Posts /by Blick FeldThe jury, led by German Silicon Valley legend Andreas von Bechtolsheim, honors Munich-based start-up company in “Start me up!”, a contest for new founders
Munich. Blickfeld, a leading provider of solid-state LiDAR technology, has been awarded 100,000 Euro for achieving first place in the “Start me up!” contest, which is organized by the business magazine BILANZ. The Munich-based start-up competed with a total of 1,200 applicants, ten of whom had reached the final round.
This year’s jury chairman was Andreas von Bechtolsheim, multi-founder and legendary Silicon Valley investor, who was one of the first to invest in Google. Von Bechtolsheim explains the decision of the ten jury members: “LiDAR sensors make driving safer because they detect dangers quickly and precisely. The unique feature of the Blickfeld sensors is their small size: They can be integrated directly into headlights and rear-view mirrors and are also very advanced in terms of range, image resolution and field of vision.”
“The mobility of the future is an issue that occupies many people and ultimately affects all of us – Blickfeld winning the “Start me up!” award is another clear sign of this!”, says Blickfeld’s CEO Dr. Mathias Müller. “We feel that our vision of making tomorrow’s mobility more efficient and, above all, safer with our sensors has been confirmed”.
BILANZ has honored the best business ideas and innovations with the “Start me up!” award since 2015 and over time has established itself as an important contest in Germany. This year’s award winners were presented with their prizes at a ceremony held on 3 July as part of the TOA technology festival in Berlin.
LiDAR for everyone – MEMS mirrors enable LiDAR sensors for the mass market
/in Posts, Blog /by Blick FeldIn the past, LiDAR systems struggled with a number of problems: they were lacking in efficiency and robustness for use in the automotive industry. An even bigger problem was the cost of a LiDAR system: The sensors were far too expensive for the automotive mass market. Blickfeld tackles this problem. The Munich-based start-up’s technology relies on MEMS silicon components and highly automated production – and is paving the way for autonomous vehicles.
The problem: lack of robustness and high production costs
LiDAR technology is not a new invention; it has been used in various applications, such as measuring emissions in atmospheric research or remote sensing in archaeology since the 1960s. However, LiDAR systems have faced some serious problems until now:
All these points pose major problems for the automotive industry in particular, which is desperately looking for high-performance LiDAR systems with a robust and production-scaleable design. Why? Because LiDAR is essential for the autonomous cars of tomorrow. Mobility is about distances and speeds. Not-colliding is essential in road traffic – LiDAR sensors detect immediately and reliably. Experts therefore predict that several LiDAR sensors per car will be needed in the future. However, to achieve this, the problems mentioned must be overcome.
What is the root of those problems?
Classical, mechanically rotating LiDAR concepts are fragile and complex in design and production, resulting in large dimensions and high prices. Although other technologies and designs such as optical phased array and flash LiDAR have the potential to significantly reduce LiDARs in size and cost, they are still at the beginning of development or have system-related disadvantages, such as a very limited range.
The solution: MEMS-based LiDAR sensors
LiDAR sensors based on MEMS mirrors are a promising solution. Their silicon construction is already well advanced and implemented very successfully in many automotive applications. In addition, MEMS technology does not require rotating components and is therefore much more robust and durable than mechanical LiDAR systems. MEMS mirrors available on the market today have small mirror sizes and small deflection angles, as these were sufficient for their previous use. Their performance in terms of range and field of view is therefore limited.
MEMS mirrors on wafer level
The Blickfeld solution: Particularly large mirrors
Blickfeld’s LiDAR system relies on MEMS. But how does their system differ from other MEMS based LiDARs? To extend the range of the sensors, Blickfeld has developed its own MEMS mirrors. With generous dimensions of more than 10 millimeters mirror diameter, a high proportion of incident light can be directed onto the photodetector. Thus, the LiDAR reliably detects even weakly reflecting objects at a distance of more than 180 meters. In comparison, conventional MEMS mirrors have diameters of only a few millimetres and small deflection angles, which reduces the range and field of view accordingly when used in LiDARs.
Further advantages of the MEMS mirror used in Blickfeld products are:
Blickfeld Cube LiDAR sensor mounted on a car roof
How does Blickfeld address the problem of production?
The MEMS mirrors developed by Blickfeld solve three of the four problems mentioned above: The company’s LiDARs are space-saving, robust and performant. But how does Blickfeld tackle the problem of cost-intensive production? By manufacturing the mirrors with low-cost photolithographic production techniques that allow highest precision with extreme scalability, so-called MEMS silicon manufacturing. In a highly automated process, a standard silicon wafer with a diameter of 200 millimeters is turned into hundreds of MEMS components simultaneously. This method, which has been tried and tested in the semiconductor industry for decades, enables the technology to conquer the mass market.
The MEMS mirror is embedded in a ‘commercial off-the-shelf’ structure, i.e. commercially available standard components. These laser and detector units, that are available on the market, enable a cost-effective and scalable production of the sensors.
Autonomous cars and so much more
The use of LiDAR sensors extends far beyond the automotive industry and the fields of application are versatile. In order to take advantage of the technology, Blickfeld has eliminated the major problems of LiDAR systems and has made them accessible to the mass market. The LiDAR era has only just begun!
Blickfeld and Koito explore advanced technologies for the development of LiDAR that can be fully integrated into headlight
/in Company News, Posts /by Blick FeldMunich, Germany and Tokyo, Japan. Blickfeld, a leading provider of solid-state LiDAR technology, and Koito Manufacturing, the leading global tier-one supplier of exterior automotive lighting, announced today that they will explore technologies to develop a LiDAR sensor that can be fully integrated into a headlight.
The integration of Blickfeld’s LiDAR into Koito headlamps will enable automobile manufacturers to possess breakthrough LiDAR technology in which the sensor is fully integrated into the vehicle, which will in turn facilitate unprecedented progress in serial Advanced Driver Assistance Systems (ADAS) and Autonomous Vehicle systems (AV).
Blickfeld’s 3D solid-state LiDAR technology is designed to meet the highest automotive performance requirements. The core of the Blickfeld LiDAR is a proprietary silicon MEMS mirror specifically developed for LiDAR applications. This enables not only safe and in-depth information about the surrounding environment, but also mass-market availability. The compact design of the miniature solid-state LiDAR by Blickfeld allows direct integration into a vehicle’s lighting system, enabling real-time 3D mapping and object detection, classification, and tracking, without marring the design of the vehicle.
Dr. Mathias Müller, co-founder and CEO of Blickfeld: “With its renowned expertise and strong market position, Koito is a proven pioneer in the field of automotive headlights. We have been working very successfully with the Koito team since early 2018 and are thrilled to develop the next generation of lighting products.”
Yuji Yokoya. Executive Vice President of Koito: “Koito has been in search of innovative, high-performance LiDAR technology from around the world, and among what we have found, we regard Blickfeld as one of the most promising companies in their field”.
